Mercedes Steering Lock Fault
With their sleek designs, advanced technology, and powerful engines, Mercedes always provide high-quality luxury cars and have done so for many years. The Mercedes A180 Sport is the perfect example of this. However, a number of A180 owners have reported a steering lock fault, and we were recently visited by a customer who was experiencing this exact problem.
Our team at JDK Automotive understands that unresolved car problems can lead to frustration and disappointment, especially when previous attempts at repair have been unsuccessful. Thankfully, our experience and expertise as an independent Mercedes-Benz garage allowed us to identify the problem with the A180 Sport and provide a solution that worked.
Find out how by reading on!
Exactly What Does a Steering Lock Do?
A steering lock is a security feature that prevents the steering wheel from turning when a vehicle is switched off. After turning off the car and removing the ignition key, Mercedes-Benz vehicles automatically activate the steering lock. The system can also be activated manually by using a switch or button on the centre console or dashboard. It is designed to deter thieves by immobilising the steering system, making it difficult for someone to steer or drive the vehicle.
When Your Mercedes-Benz Steering Lock Fails, What Happens?
When the steering lock malfunctions, the steering wheel is locked in place, making it difficult, or indeed impossible, to steer the vehicle. A malfunctioning steering lock can be dangerous, so it’s crucial that you act as soon as possible.
When contacting us for help with this issue, we first recommend our customers try to resolve the problem themselves by simply attempting to disengage and re-engage the steering lock, following these straightforward steps:
- Make sure the vehicle is parked and not moving.
- Insert the key into the ignition.
- Apply gentle turning force to the steering wheel while keeping the key inserted.
- Listen and feel for a click or release, indicating that the steering lock has disengaged.
- Align the wheels by centring the steering wheel.
- To re-engage the steering lock, turn the ignition key back to the “Lock” or “Off” position while holding the steering wheel centred.
If this approach doesn’t work, we recommend you consult our Mercedes specialist at JDK Automotive right away for expert guidance and assistance.
Fixing a Steering Lock Fault on a Mercedes A180 Sport
The steering lock malfunction in a Mercedes A180 Sport can be caused by a number of factors.
In Mercedes-Benz vehicles, the steering lock system consists of two main parts: the steering lock actuator and the steering lock module. The actuator is an electric motor that physically engages or releases the steering lock, while the module is like a computer that controls the actuator. The module receives signals from various sensors in the vehicle and decides when to lock or unlock the steering. Together, these components ensure that the steering wheel is locked when the car is off, adding security to the vehicle.
Having problems with your Mercedes-Benz steering lock could be the result of a malfunctioning actuator, faulty module or faulty wiring. It could even be an electrical problem with a different component. Having your Mercedes-Benz inspected by JDK Automotives Mercedes-Benz experts will help diagnose and correct the problem.
At JDK Automotive, our Mercedes technicians use a multi-step diagnostic process to determine the root cause of the problem and decipher if it is mechanical or electrical., We also inspect other parts of the vehicle to make sure no additional problems are causing the steering lock to malfunction.
During this diagnostic process, we look for clues to help build a picture of what may be wrong with a vehicle, like our customer’s Mercedes A180 Sport. The three main clues were found in this case were:
- There was a problem with the steering lock
- There was a problem with the immobiliser
- There was a problem recognising the key
Our Mercedes expert technician began identifying the underlying cause of the problem based on this information.
- Inspection: In addition to checking for corrosion or damage to the wiring and connections, we visually examined the steering lock and the surrounding area for signs of damage or wear.
- Diagnostic evaluation: Using Mercedes dealer-level software, we analysed all diagnostic fault codes stored in the car’s computer system. The codes indicate a problem with the steering lock system, which would have helped us narrow down the investigation, but this A180 showed no fault codes.
- System test: In order to test the steering lock control module, we once again used dealer-level software to check for communication between the module and other control units in the car, to check for inputs and outputs, and to confirm the module’s supply voltage.
- Actuator test: Last but not least, we performed a test on the steering lock actuator to ensure it functioned correctly and could lock and unlock the steering wheel.
Based on the results of these tests, we found that the steering lock control module was defective. As a result, our expert technician replaced the steering lock control module with a genuine Mercedes-Benz replacement part. We never compromise on the quality of the parts we use at JDK Automotive, and we take pride in providing high-quality service and expertise.
Resolving the Problem
Replacement of the steering lock control module on a Mercedes-Benz should only be performed by expert technicians due to the specialised knowledge and equipment needed to successfully complete this fix. Depending on the model and year of the Mercedes, the specific steps for replacing the module vary, so our Mercedes-Benz specialist followed these steps for our customer’s A180 Sport :
- Diagnose the issue: Before replacing the steering lock control module, our Mercedes technician correctly diagnosed the issue and confirmed that the module was the source of the problem.
- Remove the module: Our technician then removed the steering lock control module from the vehicle. Models vary in where they are located. They can be found under the steering wheel, in the dashboard, or in the engine compartment.
- Replace the module: After removing the old module, our technician installed the new one.
- Re-program the module: Our technician then reprogrammed the new module after installing it so that it would be recognised by the vehicle’s computer system and function properly.
- Test drive the vehicle: Our technician then test-drove the vehicle to ensure that the steering lock and the immobiliser system were functioning as they should.
- Clear fault codes: Last but not least, our technician cleared fault codes from the vehicle’s ECM (Engine Control Module) to ensure that everything was working properly.
It is important to note that the steering lock module is programmed to recognise the unique code of the lock cylinder installed in the vehicle. Replacement of the lock cylinder will result in a different code that will not initially be recognised by the steering lock module.
After replacing the lock cylinder, the steering lock module must be recoded to recognise the new lock cylinder in order to function properly. The steering lock may not work properly if the steering lock module is not re-coded after replacing the lock cylinder, which may compromise the safety of your Mercedes-Benz.
With our skilled and experienced technicians, we can diagnose and fix Mercedes problems accurately and efficiently. The Mercedes A180 Sport owner was able to collect their fully fixed vehicle in no time!
